Supermicro SuperChassis 847E1C-R1K28JBOD
Rackmount 4U w/ 44x Hot-swap HDD bays
Supermicro Products
Click here to jump to more pricing!
Specifications:
| Product SKUS | |
|---|---|
| CSE-847E1C-R1K28JBOD | SuperChassis 847E1C-R1K28JBOD |
| Form Factor | |
| 4U SAS3 JBOD storage chassis | |
| Drive Bays | |
| 44 x 3.5" hot-swap HDD bays for JBOD solution | |
| Qualified SAS Controllers | |
| AOC-SAS3-9300-8E: SAS 12Gb/s PCIe 3.0 8-Port Host Bus Adapter AOC-SAS3-9380-8E: SAS 12Gb/s PCIe 3.0 8-Port MegaRAID Controller |
|
| Backplane | |
| 24-port 4U SAS3 12Gbps single-expander backplane, support up to 24x 3.5-inch SAS3/SATA3 HDD/SSD 20-port 4U (SC847E1C JBOD) SAS3 12Gbps single-expander backplane (rear), support up to 20x 3.5-inch SAS3/SATA3 HDD/SSD |
|
| Front Panel | |
| Buttons | Power On/Off button System Reset Button Unit Identification (UID) button |
| LEDs | 1 Network Activity LEDs Fan Fail/System Over Heat LED Power Status LED Power Fail LED Unit Identification (UID) LED |
| System Cooling | |
| Fan | 7 x 8cm hot-swap redundant PWM cooling fan(s) |
| Power Supply | |
| 1U 1280W Redundant Platinum 95%+ Super Quiet Power Supply with PMbus | |
Pricing Notes:
- Pricing and product availability subject to change without notice.
